Toolbox
All the resources you need to plan, design, and deliver SOLARSTONE projects in one place. Access documentation, technical datasheets, BIM models, planning tools, and installation guides - built to support professionals at every stage of the project.
Solar Full Roof™
A building-integrated photovoltaic (BIPV) roofing system for in-roof solar installations, combining roof covering, weather protection and electricity generation.
Peak Power: 430 Wp
Density: 215 Wp / m²
Wind uplift: 2400 Pa
Snow load: 5400 Pa
Hail: Ø 25 mm at 23 m/s
Electrical Safety: Class II
Fire Class: Broof (t1); Broof (t2)
Dimensions: ~1,850 × 1,300 mm
Area: ~2.4 m²
Exposed area: ~2.0 m²
Weight: ~28 kg; ~13 kg / m²
Standard full-size, aluminium-framed glass/glass PV modules with EVA/POE encapsulation integrate directly into the roof structure using SOLARSTONE’s patented Click-On™ framing and mounting system. Combined with a W1-rated, solar-ready roof underlay membrane, the system forms part of the building envelope, providing weather protection, mechanical resistance and fire protection while creating a continuous energy-generating roof surface.
Technical Documentation
Installation Documentation
Solar Tiled Roof™
A building-integrated photovoltaic (BIPV) roofing system for in-roof solar installations, combining roof covering, weather protection and electricity generation.
Peak Power: 105 Wp
Density: 185 Wp / m²
Wind uplift: 2400 Pa
Snow load: 5400 Pa
Hail: Ø 25 mm at 23 m/s
Electrical Safety: Class II
Fire Class: Broof (t1); Broof (t2)
Dimensions: ~1,793 × 393/438 mm
Area: ~0.55 m²
Exposed area: ~0.55 m²
Weight: ~28 kg; ~13 kg / m²
Custom-sized, aluminium-framed glass/glass PV modules with EVA/POE encapsulation integrate directly into the roof structure and interface with a range of traditional flat, profiled and barrel roof tiles. Combined with a W1-rated, solar-ready roof underlay membrane, the system forms part of the building envelope, providing weather protection, mechanical resistance and fire protection while creating a continuous energy-generating roof surface.
Technical Documentation
Installation Documentation
BIM-models
Solar Power Set™
A standardised, ready-to-install configuration of the Solar Full Roof™ BIPV system for partial roof integration.
Sizes: Large; Medium; Small
Peak Power: 8.60 kWp; 6.88 kWp; 5.16 kWp
Density: 215 Wp / m²
Wind uplift: 2400 Pa
Snow load: 5400 Pa
Hail: Ø 25 mm at 23 m/s
Electrical Safety: Class II
Fire Class: Broof (t1); Broof (t2)
The set combines predefined layouts of Solar Full Roof™ 430 Wp BIPV modules with the required mounting, transition flashing, sealing, grounding and cable-management components. Supplied as a complete installation package, it simplifies system design, procurement and on-site installation while integrating with compatible tiled and metal roofing systems.
